YANMAR YDP30N-Y1 DIESEL WATER PUMP 3x3
YANMAR YDP30N-Y1 DIESEL WATER PUMP 3x3
YANMAR YDP30N-Y1 DIESEL WATER PUMP 3x3
YANMAR YDP30N-Y1 DIESEL WATER PUMP 3x3

YANMAR YDP30N-Y1 DIESEL WATER PUMP 3x3

AED 5,600.00

Shipping calculated at checkout

Quantity:
Product Overview
Highlights
  • Model:YDP30N-Y1 (Fresh Water)
  • Pump Type:Portable, Self-Priming Fresh Water Pump
  • Suction & Discharge Diameter:80 mm (~3″)
  • Maximum Flow / Capacity:900 L/min
  • Suction Lift:7.0 m
  • Maximum Total Head:28.0 m
  • Engine Model:L48N6-PYI2 (4-stroke, air-cooled diesel)
  • Engine Displacement:219 cc
  • Engine Maximum Output:3.5 kW @ 3600 rpm
  • Continuous Engine Output:3.1 kW @ 3600 rpm
  • Fuel (Diesel) Tank Capacity:13 L
Product Description

The YANMAR YDP30N-Y1 is a rugged and dependable portable water pump powered by a Yanmar L-series air-cooled diesel engine. Designed for clean (fresh) water applications, this 3-inch (80 mm) suction and discharge pump is ideal for construction dewatering, agricultural irrigation, flood management, and other water-transfer tasks where reliable, engine-driven pumping is required.

The self-priming design enables the pump to start and re-prime easily, simplifying setup. It’s built with durable materials to withstand rough conditions, and the compact frame ensures portability. With a large 13-liter fuel tank, the YDP30N offers long operating hours, making it a practical solution for remote or off-grid sites.

⭐ Key Features

  • Reliable Yanmar Diesel Engine
    Uses a proven L-series 4-stroke, air-cooled Yanmar diesel engine designed for long life and low fuel consumption.

  • Self-Priming Capability
    The pump is self-priming, making it easy to start even if the suction line is initially empty or has air.

  • Compact & Portable Design
    Light frame (dry weight ~ 46 kg) and compact build make it easy to transport and deploy on job sites.

  • Large Fuel Capacity
    A 13-liter fuel tank supports extended run times, reducing downtime for refueling.

  • Strong Flow Performance
    High flow rate (900 L/min) to handle significant water transfer needs efficiently.

  • Good Head & Lift
    28 m maximum head and 7 m suction lift make it suitable for a wide range of pumping scenarios.

  • Durable Construction
    Components like the impeller and casing are made from cast iron or cast steel, providing durability and resistance to wear.

  • Low Noise & Vibration
    Designed for comfortable operation, the engine is optimized to minimize vibration and noise, which is especially helpful in sensitive environments.

  • Wide Application Range
    Ideal for construction dewatering, agricultural irrigation, flood control, and other fresh-water pumping tasks.

  • Optional Electric Start Variant
    While the base YDP30N-Y1 has a recoil start, Yanmar offers an electric-start version (YDP30N-E) for easier starting.
