AED 1,850.00

Shipping calculated at checkout

Quantity:
Product Overview
Highlights
  • Model:PV9000-48 S6.0
  • AC Output
  • Rated Output Power:6.0 kW
  • Surge Power:12.0 kVA
  • Output Voltage:208 / 220 / 230 / 240 VAC (Selectable)
  • Waveform:Pure Sine Wave
  • Frequency:50 / 60 Hz ±0.1%
  • Transfer Time:10 ms
  • Max. Efficiency:94%
  • AC Input
  • Grid/Generator Voltage:90 ~ 280 VAC (Normal Mode)
  • UPS Mode Voltage:170 ~ 280 VAC
  • Frequency:50 / 60 Hz (Auto Adaptive)
  • Solar Charger Type:MPPT
  • Max. PV Input Power:9000 W
  • Max. PV Input Voltage:500 VDC (Open Circuit)
  • MPPT Operating Range:60 ~ 450 VDC
  • Max. PV Input Current:27 A
  • Max. PV Charge Current:120 A
  • Rated Voltage:48 VDC
  • Supported Types:Lithium & Lead-Acid
  • Max. AC Charge Current:120 A
  • Max. Combined Charge (PV + AC):120 A
  • Communication:LCD, RS232, RS485, USB, Dry Contact
  • Display Option:Optional RGB Display
  • Monitoring:Optional WiFi Module
  • Protection Rating:IP21
  • Operating Temperature:-10 °C to +50 °C
  • Dimensions (W*H*D):410 x 336 x 110 mm
  • Net Weight:10 kg
Product Description

The Sunride PV9000-48 S6.0 is a high-performance 6.0 kW hybrid inverter designed for robust and efficient residential or commercial energy systems. Operating on a 48V battery platform, it integrates a powerful 120A MPPT solar charger with a pure sine wave inverter, offering a perfect balance between high power output and efficient energy management. With features like dual AC outputs, generator compatibility, and optional smart monitoring, it is engineered for users seeking reliable off-grid power, extensive backup capabilities, and significant energy savings.

Key Features

  • High-Efficiency 6kW Output: Delivers a continuous 6.0 kW of pure sine wave AC power with a high surge capacity of 12.0 kVA, capable of starting and running demanding household appliances, power tools, and motorized equipment.

  • 48V Battery System: Operates on a 48V battery bank, which is more efficient for higher-power systems compared to 24V, reducing current and allowing for use with smaller gauge cables, especially over longer distances.

  • Powerful Solar Charging: Features a built-in 120A MPPT solar charger that can utilize up to 9,000W of solar panels, enabling rapid battery recharging and maximizing solar self-consumption.

  • Dual AC Outputs: Includes dual AC output circuits, providing superior load management flexibility to separate critical and non-essential loads for improved control and safety.

  • Generator Compatible: Seamlessly integrates with a generator for automatic backup battery charging during prolonged periods of cloudy weather or high energy demand, ensuring an uninterrupted power supply.

  • Lithium Battery Optimized: Fully supports communication with Lithium battery BMS and includes a lithium battery activation feature, ensuring optimal performance, longevity, and safety when used with modern lithium iron phosphate (LiFePO4) batteries.

  • Grid Interaction & Feed-in: Can be connected to the utility grid and supports feed-in functionality, allowing for potential energy export to the grid (where legally permitted) to earn credits or reduce energy costs.

  • Advanced Monitoring & Display: Offers an optional RGB display for an enhanced user interface and an optional WiFi module for remote monitoring and control via smartphone app or web portal.
