AED 1,020.00

Shipping calculated at checkout

Quantity:
Product Overview
Highlights
  • Model:PV5000-24 S3.6
  • AC Output
  • Rated Output Power:3.6 kW
  • Surge Power:7.2 kVA
  • Output Voltage:208 / 220 / 230 / 240 VAC (Selectable)
  • Waveform:Pure Sine Wave
  • Frequency:50 / 60 Hz ±0.1%
  • Transfer Time:10 ms (UPS/APP Mode) / 20 ms (Generator Mode)
  • Max. Efficiency:92.7%
  • AC Input
  • Grid/Generator Voltage:90 ~ 280 VAC (Normal Mode)
  • UPS Mode Voltage:170 ~ 280 VAC
  • Frequency:50 / 60 Hz (Auto Adaptive)
  • Solar Charger
  • Type:MPPT
  • Max. PV Input Power:5000 W
  • Max. PV Input Voltage:500 VDC (Open Circuit)
  • MPPT Operating Range:40 ~ 450 VDC
  • Max. PV Charge Current:100 A
  • Battery
  • Rated Voltage:24 VDC
  • Supported Types:Lithium & Lead-Acid
  • Max. AC Charge Current:100 A
  • Max. Combined Charge (PV + AC):100 A
  • General Data
  • Communication:LCD, RS485, CAN, RS232, Dry Contact
  • Monitoring:Optional WiFi Module
  • Protection Rating:IP20
  • Operating Temperature:-10 °C to +50 °C
  • Dimensions (H*W*D):420 x 284 x 94 mm
  • Net Weight:6.4 kg
Product Description

The Sunride PV5000-24 S3.6 is a versatile and powerful 3.6 kW all-in-one hybrid inverter, designed for robust off-grid and backup power applications. It integrates a high-capacity MPPT solar charger, a pure sine wave inverter, and an AC battery charger into a single compact unit. Supporting both lithium and lead-acid batteries, it is an ideal solution for home energy storage systems, cabins, workshops, and providing reliable backup power during grid outages.

Key Features

  • All-in-One Power Hub: Combines a 3.6 kW pure sine wave inverter, a 100A MPPT solar charger, and a 100A AC battery charger in one device, simplifying system design and installation.

  • High-Capacity Solar Charging: With a massive 5,000W PV input capability and a 100A charge current, it can efficiently harness energy from large solar arrays, significantly reducing grid dependency and generator runtime.

  • Dual Battery Support & Activation: Compatible with both modern Lithium and traditional Lead-acid batteries. Features a dedicated lithium battery activation function, ensuring seamless integration with lithium battery management systems (BMS).

  • Ultra-Fast Transfer Switching: Provides a quick 10ms switchover time in UPS/APP mode, ensuring critical appliances and electronics continue to run without interruption during a grid power failure.

  • Generator & Grid Integration: Can be connected to a generator for backup charging and accepts a grid input. It also supports feed-in to the grid (subject to local regulations and setup), allowing for potential energy export.

  • Wide PV Voltage Range: The MPPT operates efficiently with a wide input range of 40-450VDC, offering flexibility in solar panel string configuration and ensuring high energy harvest even in low-light conditions.

  • Remote Monitoring & Control: An optional WiFi module enables remote monitoring of system performance, energy production, and consumption, as well as control via a dedicated App or Web portal.

  • User-Friendly Design: Features a clear LCD display for local status checks and a detachable dust cover to protect communication ports, ensuring long-term reliability.
