SAER M600B V400 2HP 3PH PMP

The M600B V400 is a high-performance electric centrifugal pump designed for efficient fluid transfer in industrial, commercial, and residential applications. Built with corrosion-resistant stainless steel and durable thermoplastic components, this pump is ideal for handling clean water and other non-aggressive fluids. With a robust motor and compact design, the M600B ensures reliable operation, easy installation, and long service life in a variety of pumping systems.

Key Features

• Corrosion-Resistant Construction:

  • Pump Body & Seat Disc: Stainless Steel AISI 304 (1.4301)

  • Shaft: Stainless Steel AISI 431 (1.4057)

  • Impeller & Diffuser: Thermoplastic Resin

• Reliable Sealing System:

  • Mechanical Seal: BVEG (Graphite/Alumina Oxide/EPDM)

• High-Efficiency Motor:

  • Manufacturer: SAER

  • Rated Power: 1.5 kW with Service Factor 1.15

  • Suitable for continuous duty cycles

• Compact & Sturdy Design:

  • Optimized dimensions for easy integration into existing systems

  • Key dimensions: Height (H) = 165 mm, Width (w) = 325 mm

• Versatile Performance:

  • Suitable for clean water and similar fluids

  • Wide operating range: up to 6 m³/h flow and 60 m head

• Safe Operation:

  • IP44 protection against dust and water splashes

  • Direct starting for simple and reliable operation

Typical Applications

• Water supply and boosting systems

• Irrigation and agricultural water transfer

• Industrial cooling and circulation systems

• Pressure boosting in residential and commercial buildings

• General purpose fluid transfer

Compliance & Standards

• Built in accordance with international electrical and mechanical standards

• Motor designed for reliable performance under continuous duty (S1)

This pump combines durability, efficiency, and versatility, making it a suitable choice for a wide range of fluid handling applications where reliability and corrosion resistance are essential.
