Product Overview
Highlights
  • Model Series:CF
  • Pump Type:Self-Priming Positive Displacement Gear Pump
  • Speed:1150 rpm
  • Max Flow Rate:1.2 m³/h
  • Max Head:61 meters
  • Max Working Pressure:10 bar
  • Self-Priming Lift:Up to 8 meters
  • Motor Options:Single-phase or Three-phase
  • Voltage/Frequency:220V-60Hz (1-phase), 220V/380V-60Hz (3-phase)
  • Max Liquid Temp:-15°C to +60°C
  • Max Ambient Temp:40°C
  • Pump Body:Cast iron with lateral threaded connections
  • Gears:One in steel, one in bronze
  • Seal:Radial rings in rubber
  • Bearings:Permanent grease lubricated
  • Motor Type:Totally Enclosed Fan Cooled (TEFC)
  • Protection Class:IP44 (IP55 available on request)
  • Insulation Class:F
SAER CF 1HP0.75KW Self-Priming Gear Pump
Product Description

The CF Series comprises robust self-priming gear pumps designed for positive displacement operation, making them ideal for handling viscous and challenging fluids. These pumps operate on the principle of two rotating geared wheels that efficiently transfer energy to the pumped liquid. With a self-priming capability of up to 8 meters, the CF pumps are well-suited for industrial applications involving thick oils, varnishes, adhesives, and other viscous liquids. Built with durable materials and available in single-phase or three-phase motor options, these pumps offer reliable performance in demanding environments.

Key Features

  • Self-Priming Design: Capable of lifting liquids up to 8 meters suction head

  • Positive Displacement: Ideal for viscous fluids with consistent flow rates

  • Robust Construction: Durable cast iron body with steel and bronze gears

  • Thermal Protection: Single-phase models available with built-in thermal overload protection

  • Versatile Motor Options: Available in both single-phase and three-phase configurations

  • By-Pass Valve Compatible: Flow can be controlled via by-pass valve on discharge side

  • High Pressure Capability: Handles working pressures up to 10 bar

  • Maintenance-Friendly: Permanent grease-lubricated bearings for reduced maintenance

  • Wide Temperature Range: Suitable for liquids from -15°C to +60°C

  • Quality Compliance: Performance tolerance according to UNI EN ISO 9906 – Grade 3B

Applications

  • Varnishes and paints

  • Thick oils and lubricants

  • Adhesives and glue

  • Molasses and syrups

  • Soaps and detergents

  • Greases and viscous compounds

Important Notes

  • Liquid Requirement: Must be free of any solid content

  • Flow Control: Must be done via by-pass valve on discharge side, not by outlet throttling

  • Temperature Limitation: For higher temperatures, consult sales office

  • Performance Basis: Based on continuous service with specific weight of 780 kg/m³

Manufacturing Quality

  • Brand: SAER

  • Origin: Made in Italy

  • Standards: UNI EN ISO 9906 – Grade 3B compliance

The CF Series gear pumps represent a reliable solution for handling challenging viscous fluids in various industrial applications. Their self-priming capability, robust construction, and positive displacement operation make them particularly suitable for transfer, circulation, and dosing applications where consistent performance with thick liquids is required.
