Product Overview
Highlights
  • Generating Set Model:Perkins P-33
  • Prime Power:30 kVA / 24 kW (50 Hz)
  • Prime Power:34 kVA / 27.9 kW (60 Hz)
  • Standby Power:33 kVA / 26 kW (50 Hz)
  • Standby Power:38.2 kVA / 30.6 kW (60 Hz)
  • Voltage & Frequency:380-415 V, 3 Phase, 50 Hz / 60 Hz
  • Engine Model:Perkins 1103A-33G
  • Cylinders:3, Vertical In-Line
  • Displacement:3.3 Liters
  • Aspiration:Naturally Aspirated
  • Governing Type:Mechanical
  • Compression Ratio:19.25:1
  • Gross Engine Power:324 kW (434 hp) @ 50 Hz
  • Gross Engine Power:368 kW (493 hp) @ 60 Hz
  • Alternator Make & Model:UPS / Leroy Somer UPS314G/LSA(TAL)042B
  • Insulation Class:H
  • Voltage Regulation:±1%
  • Control Panel:Deep Sea 4000 Series
  • Fuel Consumption @100% Load:7.1 L/hr (50 Hz)
  • Fuel Consumption @100% Load:8.6 L/hr (60 Hz)
  • Coolant Capacity:10.2 Liters
  • Weight:765 kg (Standard)
  • Weight:850 kg (With Soundproof Canopy)
Perkins P-33 Generating Set
Product Description

The Perkins P-33 is a robust mid-range diesel generating set designed for reliable prime and standby power applications. Built with a durable 3-cylinder Perkins engine and high-performance Leroy Somer alternator, this generator delivers stable power for medium commercial, industrial, and backup power requirements. Featuring mechanical governing, Class H insulation, and the comprehensive Deep Sea 4000 Series control system, the P-33 offers exceptional reliability and performance for continuous operation in demanding environments.

Key Features

  • Robust Perkins Engine: 3-cylinder, 3.3L diesel engine with mechanical governing for reliable operation

  • High-Capacity Performance: Delivers up to 38.2 kVA standby power for medium-load applications

  • Premium Alternator: Leroy Somer alternator with Class H insulation for superior thermal endurance

  • Advanced Control System: Deep Sea 4000 Series with LCD display and comprehensive monitoring

  • Dual Frequency Operation: Compatible with both 50 Hz and 60 Hz applications worldwide

  • Integrated Fuel System: Baseframe with integral fuel tank for approximately 8 hours of full-load operation

  • Vibration Isolation: Anti-vibration mounting pads ensure smooth operation and reduced noise transmission

  • Comprehensive Safety Features: Full protection against overspeed, low oil pressure, high temperature, and electrical faults

  • Quality Compliance: Meets BS4999, IEC 60034, VDE0530, NEMA MG 1.22, and ISO 8528 standards

  • Factory Tested: Complete load testing and system verification before dispatch

  • 12-Month Warranty: Comprehensive warranty coverage for peace of mind

Control & Monitoring

  • Generator frequency, voltage, and current monitoring

  • Engine oil pressure and coolant temperature

  • Battery voltage and charging status

  • Emergency stop functionality

  • Comprehensive fault diagnostics

  • Run hours counter and operational status
